Design and Construction
© b2 electronic GmbHDHV0086 Rev0634
Arc Management Modes
If a fault is detected during an HV test, the arc management mode
determines how the failure is managed. The “Burn on Arc” mode will condition
thefaultwhereasthe“TripoutonArc”modewillimmediatelyswitcho󰀨the
HV.
Fault detected
Burn on Arc
Dwell time starts
HV still ON
DUT energizes
Dwell time ends
Fault conditioned
Fault detected
Trip out on arc
HV automatically OFF
DUT discharges
Tripping time recorded
