BAD BOY TRACTOR
▶
Alternating returning plowing
pattern
● This pattern is useful for narrow
or short fields or poorly planned
elds in which are not easy to turn.
● In the gure, the plowing width for
(1), (2), (3) and (4) should be over-
lapped with the one for (5), (6) and
(7) for approx. 10 cm.
● For the sections (1) to (7), perform
plowing in an alternating pattern.
For the sections (8) to (19), plow
in a circular pattern.
● Refer to the sequential returning
pattern for other details.
Moving direction
Moving direction
Reverse driving
Reverse driving
Finish
Finish
A: Border
A: Border
A
A
Start
Start
(9)
(9)
(13)
(13)
(17)
(17)
(19)
(19)
(15)
(15)
(11)
(11)
(18)
(18)
(8)
(8)
(12)
(12)
(16)
(16)
(1)
(1)
(7)
(7)
(2)
(2)
(6)
(6)
(3)
(3)
(5)
(5)
(4)
(4)
(14)
(14)
(10)
(10)
●
Turning:
Turning:
