OPERATION
5
▶
Land leveling pattern
● The land leveling work may be
performed after crushing soil or
not.
● The vehicle speed can be set fast-
er when performing the land level-
ing work with soil crushed already.
● When working in a wet field, fill
the eld with a su󰀩cient amount of
water so that the trace of plowing
cannot be seen.
● The border shown in the figure
should be set a little narrower than
two times of one plowing width.
● Refer to the alternating returning
pattern for other details.
Moving direction
Moving direction
Reverse driving
Reverse driving
Finish
Finish
A: Border
A: Border
Start
Start
(15)
(15)
(11)
(11)
(9)
(9)
(13)
(13)
A
A
(14)
(14)
(10)
(10)
(4)
(4)
(5)
(5)
(3)
(3)
(6)
(6)
(2)
(2)
(7)
(7)
(1)
(1)
(8)
(8)
(12)
(12)
●
Turning:
Turning:
