The ER-9 is an external or battery powered indicator that displays rate
of flow and total flow. It also has a scalable pulse output. It has
independent programmable scale factors for rate and totalization,
allowing you to program these displayed values in different but
meaningful engineering units, such as gallons per minute and total
gallons.
The supertwist LCD display with 8 digits for total, and 4 digits plus
legend for rate, provides easy viewing at a glance. For conditions
where ambient light is poor, the display can be backlit by connecting
an external DC (10-28 VDC) power supply. A single unit can accept
NPN or dry contact inputs for low or high speed applications.
Count Input (Terminal 2):
Type: NPN Signal, or Contact Closure
Count Speed: NPN-280Hz max., Contact-95Hz max.
Logic: Low < 1.0 VDC, High > 2.0 VDC,
Minimum Pulse Width: NPN-1.78 microseconds, Contact-5ms
Maximum Input: 28VDC
Impedance: 1 Mohm to battery
Front Panel Enable Input (Terminal 5)
Type: NPN Signal, or Contact Closure; level sensitive
Maximum Input: 28 VDC
Remote Reset Input (Terminal 4)
Type: NPN Signal, or Contact Closure; edge sensitive
Frequency Response: 30 Hz (50% duty cycle)
Maximum input: 28 VDC
Pulse Output (Terminals 6 & 7)
Type: Isolated photo MOS relay
Load rating: 0.1 amp @ 30VAC/VDC
Transition time: <5ms
2
Scope of this manual
This manual contains information concerning the installation, operation
and maintenance of the Badger ER-9 indicator. To ensure proper
performance, the instructions given in this manual should be thoroughly
understood. Retain the manual in a readily accessible location for future
reference.
Installation, wiring and programming of the ER-9 is fairly simple and
straight forward. This manual is designed so as to provide you with a step
by step guide for this purpose.
Examples are provided only to facilitate programming. Your specific
application will most likely require a different set of numbers for proper
programming.
The troubleshooting section attempts to illustrate the most common
problems that can be encountered, their most likely cause and the
recommended solution. If a problem persists, please contact our techni-
cal support group at:
Badger Meter, Inc.
1-414-355-0400
Specifications
Power Source:
Type: Dual 3V Lithium batteries
(Battery P/N 62872-001)
Expected Life: 5 years (with external DC source)
Low Power Indicator: "Low Bat" flashes on display
approx. 2 weeks prior to end of battery life
Display:
Type: Supertwist LCD for use with or without backlighting
Number: 8 digits count value, 4 digits (plus dead zero) for rate
value
Height: 12mm (.472")
Backlighting: Green Illumination over viewable area with a 10 to 28
VDC supply (Terminal 8)
Physical:
Dimensions: 36mm x 72mm, 38mm deep
1.417in x 2.835in, 1.496 in. deep
Mounting: Panel Mount (mounting bracket supplied)
33mm x 68mm (+ 0.3mm) panel cutout
1.299in x 2.677in, (+ 0.012in) panel cutout
Connections: Screw terminals
Weight: Approximately 13 ounces
Powered by two replaceable 3V Lithium batteries, this unique design
allows for a new battery to be installed before removing the old one,
thereby retaining count total and program data. A low battery indicator
appears on the screen to provide a warning a couple of weeks before
the end of battery life.
The unit will operate in battery mode for at least six months. To extend
battery life to five years the unit must be connected to an external DC
power source.
Setup is quick and easy as the two front panel keys are used to scroll
through and preset values in all program mode choices.
This Product Contains Lithium Batteries.
Read This Manual Before Attempting Any Installation,
Wiring Or Operation.
General Information
