Consider the Down Arrow [ - | ↓ ] button as the "previous step" button. During a procedure, pressing this button will
go to the menu's previous selection or decrement a numeral.
Example 1: The illustration below shows the M-2000 Main Menu. The selection arrow is pointing to the Meter Setup
selection. To scroll the text down to the menu's previous selection, Exit this Menu (which is not visible on the display),
press [↓] once.
MAIN MENU
>Meter Setup
Measurements
MORE:
↑,↓ ENTER:>
Press [↓]
MAIN MENU
>Exit this Menu
Meter Setup
MORE:
↑,↓ ENTER:>
Example 2: For procedures that require you to enter a numeric value, the [-] button is used to decrement the selected
numeral. The illustration below shows the Low Flow Cutoff parameter display. Notice the cursor under the 3 in the ones'
place. In this case, press the [-] once to decrement the numeral to the value of 2.00 %.
LOW FLOW CUTOFF
% of 300.000 GPM
3.00%
CHG: +,- NEXT:E
Press [-]
LOW FLOW CUTOFF
% of 300.000 GPM
2.00%
CHG: +,- NEXT:E
The [E] button functions as an "Enter" button, or "cursor right" button.
Example 1: The illustration below shows the M-2000 Main Menu. The selection arrow is pointing to the Meter Setup
selection. Press [E] to select Meter Setup, and open the Meter Setup display.
MAIN MENU
>Meter Setup
Measurements
MORE:
↑,↓ ENTER:>
Press [E]
METER SETUP
>Exit this Menu
Scale Factor
MORE:
↑,↓ ENTER:>
In cases where you are entering a numeric value, the [E] button does not function as the "Enter" button, but rather, will move
the cursor to the right. When the cursor is at the right-most position, the [E] will now serve as the Enter key.
Example 2: The illustration below shows the Low Flow Cutoff display. The cursor is under the 3 in the ones' place. In this case,
press [E] to move the cursor to the right one digit.
LOW FLOW CUTOFF
% of 300.000 GPM
3.00%
CHG: +,- NEXT:E
Press [E]
LOW FLOW CUTOFF
% of 300.000 GPM
3.00%
CHG: +,- NEXT:E
