Badger Meter PC200 User Manual

Overview of the Setup Functions
SETUP FUNCTIONS AND VARIABLES
1. PRESET Default
11 UNIT L, m
3
, USGAL, IGAL, ft
3
, bbl, kg, ton, US ton, lb USGAL
12 DECIMALS 0, 1, 2, 3 (Ref: displayed value) 0
13 BATCH MINIMUM X,XXX,XXX quantity 0 USGAL
14 BATCH MAXIMUM X,XXX,XXX quantity 0 USGAL
15 PRESET VALUE X,XXX,XXX quantity 0 USGAL
2. OVERRUN Default
21 OVERRUN disable, enable disable
22 TIME 0.1…999.9 seconds 1.0 sec
3. Flow rate Default
31 UNIT L, m
3
, USGAL, IGAL, ft
3
, bbl, kg, ton, US ton, lb USGAL
32 TIME UNIT sec, min, hour, day minute
33 DECIMALS 0, 1, 2, 3 (Ref: displayed value) 0
34 CALCULATION per 1…255 pulses 10
35 Cutoff 0.1…999.9 seconds 30.0 sec
4. ALARM Default
41 NO-FLOW alarm 0.0…999.9 seconds 0.0 sec
42 LOW flow rate alarm 0000.000…9,999,999 0 USGAL
43 HIGH flow rate alarm 0000.000…9,999,999 0 USGAL
44 DELAY flow rate alarm 0.0…999.9 seconds 0.0 sec
45 RESET flow rate alarm automatic, manual, stop batch auto
5. DISPLAY Default
51 DISPLAY Increase, decrease increase
52 BACKLIGHT brightness Off, 20%, 40%, 60%, 80%, 100% 100%
53 DIM BACKLIGHT
Off, 20%, 40%, 60%, 80%, 100%
100%
6. FLOW METER Default
61 UNIT K-FACTOR L, m
3
, USGAL, IGAL, ft
3
, bbl, kg, ton, US ton, lb USGAL
62 K-FACTOR 0.000010…9,999,999 1
7. CONTROL Default
71 RELAY 2 batch, preclose, HI flow, LO flow, no-flow, any flow, pulse, pre-warn, end of batch, off Batch
72 TRANSISTOR 1 batch, preclose, HI flow, LO flow, no-flow, any flow, pulse, pre-warn, end of batch, off Batch
73 TRANSISTOR 2 batch, preclose, HI flow, LO flow, no-flow, any flow, pulse, pre-warn, end of batch, off Pulse
74 TRANSISTOR 3 batch, preclose, HI flow, LO flow, no-flow, any flow, pulse, pre-warn, end of batch, off Any flow
75 PRECLOSE volume X,XXX,XXX quantity 0 USGAL
76 PREWARN time 0.1, 999.9 sec 0.0 sec
77 PULSE WIDTH 0.001, 9.999 sec 0.000 sec
78 PULSE PER X,XXX,XXX quantity 1000 USGAL
79 PULSE ACCORDING Acc. Total, batch Acc.Total
8. OTHERS Default
81 MODEL PC200 PC200
82 SOFTWARE VERSION 03.____.____ —
83 SERIAL NO. --.--.--- —
84 PASSWORD 0000, 9999 0000
85 KEYBOARD LOCK Start, hold, preset, control, all, off off
86 TAGNUMBER 0000000, 9999999 0
Table 2: Setup functions overview
Industrial Process Controller, Model PC200
Page 22 April 2017CTL-UM-00483-EN-07
