7.11 Specications
Figure 22: Specications
Command signal 0(4)...20 mA, Ri approx. 50 Ω
0(2)...10 V, Ri > 100 kΩ
Feedback signal 0(4)...20 mA, load 500 Ω
0(2)...10 V
corresponds to the command signal
Indicator LEDs
Potentiometer 1000 Ω
Relay Relay contacts max.
250 V / 50/60 Hz, 2 A
Power supply 24 V AC /110 V AC / 230 V AC
Terminals Snap-t terminals for 1.5 mm
2
Solid wire or wire with wire end ferrules
Ambient temperature -10 °C...+50 °C
