5.12 Information on the battery menu
Information Displayed
in the Speed Field
Explanation
b01 current temperature
b09 relative state of charge
b10 absolute state of charge
b11
charge/discharge cycle
b13
period since last charge
. . . . . . . . . .
USER MANUAL DP C10.UART
Unit
d00
℃
b04 total voltage V
d01 voltage cell 1 V
d02 voltage cell 1 V
dn voltage cell n V
b06 average current A
b07 remaining capacity Ah
b08 full capacity Ah
b12 longest period without charge h
h
cells amount
OVERVIEW OF PRODUCT
5.13 Error code record
E00-E09 indicate the error codes stored, and the maxium up to 10 screen shots and
E00 present the latest error.
