BAFANG DP C10.UART - Overview of Product; Specifications and Parameters of the Display; Appearance and Dimensions

7
1 Specifications and Parameters of the Display
• 24V / 36V / 43V / 48V Power Supply
• Rated Current: 10mA
• Maximum Operating Current: 30mA
• Power-off Leakage Current: <
1uA
• Operating Current Supplied to the Controller: 50 mA
• OperationTemperature: -20℃— +60℃
• Storage Temperature: -20℃— +60℃
• Waterproof Grade: IP65
• Storage Humidity: 30 % -- 70 %
2 Appearance and Dimensions
2.1 Materials and Dimensions
•
•
The shell is made of PC.
The liquid crystal display is made of hardened PMMA.
USER MANUAL DP C10.UART
OVERVIEW OF PRODUCT
The matching kits also should be compatible with above
mentioned protocol and other BAFANG's mpatible protocol.
•
•
This product conforms to <<The Technical
Specification and Standard of design for
BAFANG's electrical component>> and is based
on << BAFANG Communication Protocol-V5.6>>
