REFRIGERATOR MODEL RML9330/RM8550/
RMS8550/RM8500 OPERATION
1= Energy selector dial
2= Off
3= 230v Operation
4= 12v Operation
5 = Gas Operation
Switch on the appliance by turning the energy
selection switch (1) clockwise to the desired
energy.
(3) 230v to be used when on site mains
(4) 12v to be used in transit or off grid
In order to prevent discharge of the
on-board battery, 12v operation should
only be used while the car is running.
Prior to starting the refrigerator in gas mode:
• Open the gas cylinder valve.
• Open the shut-off valve for gas supply to
the refrigerator.
1. Turn the rotary selector switch (1) to the
flame position.
2. Turn the temperature selector (2) clockwise,
push in and hold. Keep the controller button
depressed.
3. Igniter : Press button (3) of battery igniter
down and keep it depressed. The ignition
process is activated automatically.
4. Once the flame ignites, the pointer of
galvanometer (4) begins moving into the green
range. The refrigerator is operational. Keep
knob (2) depressed for approx. 15 seconds and
finally release it.
SETTING OF COOLING COMPARTMENT
T
EMPERATURE
Select the desired cooling compartment
temperature by turning the rotary knob (2).
The scale starts with MIN position (small bar
= highest temperature) and climbs up to MAX
position (large bar = lowest temperature).
• Please select the medium setting (A) for
ambient temperatures between +15°C
and+25°C. The unit operates within its
optimum performance range.
• 12v operation: The refrigerator operates
without thermostatic control (continuous
operation).
Each refrigerator with manual ignition is
equipped with an automatic flame safety valve
which interrupts the gas supply after approx.
30 seconds when the flame has extinguished.
The refrigerator must be operated using
liquefied gas (propane or butane NOT natural
gas or town gas). When using LPG please
