THE SERVICE MANUAL
Pursuit II 400-2 430-4 530-4 550-4 560-5 570-6
Berths 2 4 4 4 5 6
Axles 1 1 1 1 1 1
Shipping Length 5450mm 6500mm 7400mm 7400mm 7400mm 7400mm
Internal Length 4180mm 5226mm 5713mm 5713mm 5713mm 5713mm
Overall Width 2236mm 2236mm 2236mm 2236mm 2236mm 2236mm
Overall Height (including aerial) 2610mm 2610mm 2610mm 2610mm 2610mm 2610mm
Maximum Headroom 1960mm 1960mm 1960mm 1960mm 1960mm 1960mm
Body Length (excluding hitch) 4450mm 6550mm 6400mm 6400mm 6400mm 6400mm
1093Tyre Sizes 195/70R14 195/70R14 185R14C 185R14C 185R14C 185R14C
Awning Dimension 843cm 955cm 1045cm 1045cm 1045cm 1045cm
Tyre Pressure (PSI/Bar) 48psi 48psi 60psi 60psi 60psi 60psi
MRO 965Kg 1086Kg 1237Kg 1236Kg 1242Kg 1272Kg
MTPLM 1090Kg 1232Kg 1392Kg 1391Kg 1407Kg 1446Kg
Opt Equipment Payload 0 0 0 0 0 0
Total User Payload 125Kg 146Kg 155Kg 155Kg 165Kg 175Kg
Max Static Load on the Coupling
Head
100Kg 100Kg 100Kg 100Kg 100Kg 100Kg
Wheel Bolt Torque 130Nm 130Nm 130Nm 130Nm 130Nm 130Nm
Gas Locker Capacity 3.9kg & 6kg 1x6kg+1x3.9kg 2x6kg 2x6kg 2x6kg 2x6kg
