7-10 VS1MD AC Drive User Manual
P40 Frequency Setting Method
Range: 1
2
3
4
5
6
7
= Digital Keypad
= Analog V1 1: -10 - +10V
= Analog V1 2: 0 ~ +10 V
= Analog Terminal I: 0 - 20mA
= Analog Terminal V1 Mode 1+ Terminal I
= Analog Terminal V1 Mode 1+ Terminal I
= Analog RS485
Default:
1
Access Configurable
See Also:
t32-t33, F60
Sets the source of the speed reference to the drive.
1 = Keypad:Drive output frequency is set in the operation mode by pressing
the up/down keys. The drive immediately responds to the new setting
without pressing the enter key.
2 = Analog V1 Mode 1:Drive output frequency is set via a +/- 10V signal
applied to analog input terminal V1.
3 = Analog V1 Mode 2:Drive output frequency is set via a 4~20mA signal
applied to analog input terminal V1.
4 = Analog I:Drive output frequency is set via a 4~20mA signal applied to
analog input terminal I.
5 = Analog V1 Mode 1 + I:Drive output frequency is set via the sum of a
+/-10V signal applied to V1 and a 4~20mA signal applied to terminal I.
6 = Analog V1 Mode 2 + I:Drive output frequency is set via the sum of a
0~10V signal applied to V1 and a 4~20mA signal applied to terminal I.
7 = RS485:Drive output frequency is controlled via the RS485
communications port.
P41 Accel Time
P42 Decel Time
Range: 0 - 6,000 [sec]
Default:
P41 = 5.0, P42 = 10.0
Access Tunable
See Also:
P42, P36, H70, H71
Sets the Accel/Decel time of the drive. When using the multiple accel/decel
curves with preset speeds, this ramp serves as accel/decel time 0.
H71 can be used to scale the accel/decel units and H70 determines if the
time to accel/decel is relative to P35 (Frequency High Limit) or the delta
change of running frequency to set frequency.
