7-40 VS1MD AC Drive User Manual
7.6 Function Group 2 Parameters
H0 Jump Code
Range: 0 - 95
Default: 0
Access Tunable
Sets the code to jump directly to a specific parameter within the group.
H1 Last Fault 1
H2 Last Fault 2
H3 Last Fault 3
H4 Last Fault 4
H5 Last Fault 5
Range: n/a
Default: 0
Access Read Only
See also: H6
Stores information on the types of faults, the frequency, the current and the
Accel/Decel condition at the time of fault. The latest fault is automatically
stored in the H1 – Fault History 1. Up to the last five faults can be stored.
When a fault occurs during operation, it can be monitored in the d – display
parameters under nOn. See Chapter 9 – Troubleshooting for information on
fault codes and actions.
H6 Reset Fault History
Range: 0 - 1
Default: 0
Access Tunable
See also: H1-H5
Clears the fault history saved in H1 to H5.
