Parameter Descriptions 7-49
Volts per Hertz:
Slip
Compensation:
PID Feedback:
Sensorless
Vector:
Basic Operation of the Drive, set standard motor
parameters:
P30 – Motor Hp
P32 – Motor Rated Current
P33 – Motor PolesF30 – V/F Pattern
This function enables the motor to run in constant speed
by compensating inherent slip in an induction motor. Set
parameters:
P30 – Motor Hp
P32 – Motor Rated Current
P33 – Motor Poles
H32 – Rated Slip Freq
H34 – Motor No Load Current
H36 – Motor Efficiency
H37 – Load Inertia
H50 thru H56 (see chapter 8 for advanced PID features)
Open Loop Speed Regulated drive control. Set
parameters:
P30 – Motor Hp
P32 – Motor Rated Current
H32 – Rated Slip Freq
H34 – Motor No Load Current
H41 – Auto tuning
H42 – Stator resistance
H44 – Leakage inductance
F14 – Time for magnetizing
H41 Auto-Tuning
Range: 0 - 1
Default: 0
Access Configurable
See also: H40, H42, H44
If this parameter is set to a 1, it automatically measures the values to assign
for parameters H42 – Stator Resistance and H44 – Leakage Inductance.
H42 Stator Resistance (Rs)
Range: 0-28 [Ω]
Default: n/a
Access Configurable
See also: H40, H41, H44
This is the value of the motor stator resistance.
