10
1
3
5
6
7
8
9
10
11
13
12
14
15
16
17
18
19
20
21
22
23
24
25
26
27
4
5
6
9
2
VT150 / VT200
Ref No. Description Part no.
1 Rubber foot BPB0601
2 Inspection plug BPB0243
3 Inspection plug seal BPB0502
4 50 litre tank BPB0261
5 40mm mounting rubber BPB0272
6 Motor mounting bracket [VT150] BPB0321
7 Solenoid valve c/w cable BPB0545
8 1/8 x 6mm push fitting BPB0154
9 0.4m 6mm nylon tubing BPB0203
10 20mm mounting rubber BPB0273
11 Crankcase mounting bracket BPB0347
12 3/8 drain tap BPB0281
13a 3/8 x 10mm tube elbow [VT200] BPB0280
13b 3/8 x 10mm tube elbow [VT150] BPB0277
14 0.6m drain tube BPB0284
15 50mm tank pressure gauge BPB0658
16 Pressure switch BPB0550
17 40mm line pressure gauge BPB0657
18 Pressure regulator BPB0510
19 1/4 M adaptor BPB1078
20 On-off tap BPB1079
21 Safety valve BPB1084
22 1/4 M/F elbow BPB1139
23 3/8 M adaptor BPB0283
24 400mm Delivery pipe BPB0508
25 1/8 x 6mm elbow tube fitting BPB0044
26 3/8 M/F elbow BPB0282
27 Non-return valve BPB0656
