Bambi VT75 - VTS250 Parts Identification; VTS250 Exploded View and Part Numbers

VTS250
Ref No. Description Part no.
1 Top panel BPB0354
2 3/8BSPF x 10mm tube elbow BPB0593
3 3/8BSP Bulkhead connector BPB0749
4 Safety valve BPB1084
5 1/4BSPM x 6mm tube elbow BPB0042
6 1/4BSPF x 6mm tube elbow BPB0758
7 1/4BSP x 63mm 0-160 gauge BPB0748
8 Pressure switch BPB0550
9 1/4BSPM x 6mm tube elbow BPB0042
10 Cabinet: RH panel BPB0352
11 1/4BSPM x 10mm tube elbow BPB0276
12
Pressure regulator
BPB0510
13 1/4BSPM x 10mm tube elbow BPB0276
14 Cabinet centre panel BPB0353
15 Cabinet back panel BPB0350
16 Cooling fan BPB0727
17 Fan guard BPB0355
18 2.0HP Motor mounting bracket BPB0516
19 1/8BSPF x 6mm push fitting BPB0154
20 On/Off valve BPB1079
21 M8 Hex full nut BPB0161
22 2.0HP Crankcase mounting brkt. BPB0517
23 20mm Rubber mount BPB0273
24 M8 Flanged nut BPB0130
25 M8 Hex full nut BPB0161
26 40mm Rubber mount BPB0272
27 Cabinet LH panel BPB0351
28 1/8BSPF x 6mm elbow BPB0278
29 400mm Delivery pipe BPB0508
30 3/8BSPM x 10mm tube elbow BPB0277
31 3/8BSP M/F elbow BPB0282
32 Non-return valve BPB0656
33 Solenoid valve / cable assembly BPB0545
34 After-cooler mounting bracket BPB0336
35 Cooling fan / housing: Large BPB0767
36 Cutout / Reset switch BPB0722
37 On/Off switch APT626
38 Drain valve BPB0895
39 1/8BSPP Silencer BPB0588
40 M8 Hex full nut BPB0161
41 Cabinet base BPB0348
42 Retaining washer BPB0559
43 Spacer BPB0082
44 M6 x 35mm caphead screw BPB0131
45 Swivel castor BPB0973
46 Motor mounting plate BPB0343
47 Swivel castor c/w brake BPB0974
48 59ltr vessel BPB0230
49 Inspection plug seal BPB0502
50 1BSP Flanged inspection plug BPB0243
51 1/4BSPM x 6mm tube elbow BPB0042
52 Cabinet front panel BPB0349
53 Thermal switch BPB0732
