Bambi VT75 - VTS250 D Parts Identification; VTS250 D Exploded View and Part Numbers

20
VTS250D
Ref No. Description Part no.
1 Top panel BPB0354
2 Cooling fan BPB0727
3 Back panel BPB0350
4 Cabinet RH panel BPB0352
5 Cabinet centre panel BPB0353
6 1/4BSPF x 6mm tube elbow BPB0758
7 1/4BSP x 63mm 0-160 gauge BPB0748
8 1/4BSPM x 10mm tube elbow BPB0276
9
Pressure regulator
BPB0510
10 1/4BSPM x 10mm tube elbow BPB0276
11 1/4BSPM x 10mm elbow BPB0820
12 On/Off valve BPB1079
13 1/4BSP Regulator BPB0510
14 Drain valve BPB0895
15 On/Off switch APT626
16 Cutout/Reset switch BPB0722
17 Water bottle c/w cap and cage BPB0088
18 1/4BSPM x 10mm tube elbow BPB0276
19 Safety valve BPB1084
20 3/8BSP Bulkhead connector BPB0749
21 3/8BSPF x 10mm tube elbow BPB0593
22 Pressure switch BPB0550
23 1/4BSPM x 10mm tube elbow BPB0276
24 Aftercooler c/w fittings / guard BPB0869
25 3/8BSP M/F plated elbow BPB0282
26 3/8BSP M/F plated elbow BPB0282
27 165mm Delivery pipe BPB0728
28 600mm Delivery pipe BPB0798
29 1/8BSPF x 6mm elbow BPB0278
30 Solenoid valve / cable assembly BPB0545
31 Coalescing filter: manual drain BPB0983
32 Coalescing filter: manual drain BPB0983
33 Coalescing filter: manual drain BPB0983
34 400mm Delivery pipe BPB0508
35 600mm Delivery pipe BPB0798
36 3/8BSP M/F elbow BPB0282
37 3/8BSP Bulkhead connector BPB0749
38 Coalescing filter: manual drain BPB0983
39 165mm Delivery pipe BPB0728
40 3/8BSP Bulkhead connector BPB0749
41 3/8BSP M/F elbow BPB0282
42 3/8BSP Elbow BPB0629
43 Twin tower dryer BPB0836
44 1/4BSP Relief valve: 10bar BPB1084
45 1/4BSP M/F Extension piece BPB0150
46 3/8BSP M/F elbow BPB0282
47 59ltr vessel BPB0230
48 1/4BSPM x 6mm tube elbow BPB0042
49 Inspection plug seal BPB0502
50 1BSP Flanged inspection plug BPB0243
51 3/8BSP M/F elbow BPB0282
52 Non-return valve BPB0656
53 3/8BSPF x 10mm tube elbow BPB0593
54 Motor mounting plate BPB0343
55 Cabinet LH panel BPB0351
56 Swivel castor BPB0973
57 Swivel castor c/w brake BPB0974
58 M6 x 35mm cap head bolt BPB0131
59 Spacer BPB0082
60 Retaining washer BPB0559
61 Cabinet base BPB0348
62 M8 Hex nut BPB0161
63 Cabinet front panel BPB0349
64 After-cooler mounting bracket BPB0336
65 M8 Flanged nut BPB0130
66 20mm Rubber mount BPB0273
67 2.0HP Crankcase mounting bracket BPB0517
68 M8 Hex nut BPB0161
69 40mm Rubber mount BPB0272
70 M8 Hex nut BPB0161
71 2.0HP motor mounting bracket BPB0516
72 Fan guard BPB0355
73 Thermal switch BPB0732
