Addendum Manual Documentation Number M3640D1598
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH (815) 433-5100 -- FAX (815) 433-5104
ATTENTION: METEX USERS
This addendum contains corrections and additions to the user's manual.
Paragraph 6-12-2, page 32, of the M-3640D Digital Multimeter manual
refers to two computer programs: METEX and Scopeview. These
programs are no longer available and have been replaced by METVIEW.
This program works with Windows 3.11, Windows 95, and Windows NT.
Please use the following Installation information and NOT the information
in the manual. The Hardware Interfacing information in paragraph 6-12-1
is correct.
Installing the Supplied Software
We have included a Windows 95/NT program, named METVIEW.EXE, to
log data collected with your meter. To install the software on your hard
drive:
1. Insert the disk in drive A.
2. Click the start button in the lower left corned of the screen and choose
"Settings I Control Panel I Add / Remove Programs".
3. Click the install button and follow the directions.
Using the Software
To run the software after it has been installed, click the start button in the
lower left corner of the screen and choose "Programs I Metex I Metex".
After starting the metex program, click the setup button. A dialog box
appears that allows you to select the serial communications port, sampling
interval, and logging file. Note that the logging file can only be changed
when the “Enabled Data Logging" check box is checked. The filename
may be typed in or you can click the browse button to select where the file
should be located. Once you have completed the setup, click the OK
button.
To start collecting data from the meter, click the button labeled "start".
Data is read from the meter at the sampling interval that was selected when
you setup the software. If data logging is enabled, the data is written to a
disk file. To stop collecting data, click the button labeled "stop". Note that
this is the same button as the start button.
