14 Manual Documentation Number M3640D1598
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH (815) 433-5100 -- FAX (815) 433-5104
Allows you to interface the meter with your PC to communicate with your
PC in all function ranges. To avoid operation error, do not set your meter
at
mode during communicating with a computer.
27.
Comparison
Enables you to do the High Low Test of subsequent readings by comparing
a reading with both the stored high reference value and the stored low
reference value.
On the sub-display, Lo sign for reading less than the low reference value,
Hi sign for reading more than the high reference value and PASS sign for
middle ranges will be shown.
To store the reference values of Min/Max, see the steps of REL 2, 3.
To exit
mode, press the function key or turn the rotary switch to
an adjacent range.
28. Display for address number
To operate this address number, you can address the stored reference
values up to 10 measurements in the
and modes, each time
press UP DOWN buttons.
5-5. Annunciators
Items 29-32 describe annunciators that indicate the mode or state in which
the meter is operating.
29.
Diode Test
The value displayed is the forward voltage of semiconductor function(s) at
approximately 1 mA test current. Single 0-2.0V range.
30. AC Alternating Current or Voltage
31.
Continuity Check
Make it easy to check wiring, continuity of cables, fuses and connections.
etc.
32.
Negative Polarity
Automatically indicates negative inputs. When
is enabled,
indicates negative results of math calculations.
33. FREQ Frequency Count Mode
Can measure up to 1 MHz with 4 steps of 2, 20, 200KHz, 1 MHz (for
M-3610D/3630D/3640D).
