8-2. Special Characteristics
MODEL FUNCTION RANGE ACCURACY RESOLUTION
200 mV
2 V
20V
200V
±0.3% of rdg +1 dgt 100 uV
1 mV
10 mV
100 mV
DC VOLTAGE
100 V ±0.5% of rdg +1 dgt 1 V
200 mV ±0.8% of rdg +3 dgts 100 uV
2 V
20 V
200 V
±2.5% of rdg +5 dgts 1 mV
10 mV
100 mV
AC VOLTAGE
(True rms)
750 V ±1.5% of rdg +3 dgts 1 V
200 Ω
2 KΩ
20 KΩ
200 KΩ
2 MΩ
±0.5% of rdg +3 dgts
0.1 Ω
1 Ω
10 Ω
100 Ω
1 KΩ
M-3640D
M-3660D
RESISTANCE
20 MΩ
±1.0% of rdg +2 dgts
10 KΩ
Notes: AC Voltage (True rms)
1. The nominated accuracy is guaranteed when the input value is full-scale basis.
2. Frequency for accuracy
• 40 Hz to 20 KHz for 200 mV, 2V, 20V & 200V.
• 40 Hz to 400 Hz for 750 V.
