2 Manual Documentation Number M3640D1598
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH (815) 433-5100 -- FAX (815) 433-5104
2. SAFETY INFORMATION
2-1. Safety Requirements
This meter has been manufactured and tested in accordance with IEC 348
and DIN57411/VDE0411 Part 1: Safety Requirement for Electronic
Measuring Apparatus, Safety Class II.
This manual contains information and warnings which must be observed to
assure safe operation and maintain the meter in safe condition.
NOT FOR HIGH ENERGY INDUSTRIAL USE.
2-2. Safety Symbols
We have placed the following special markings on the panel to remind you
of the measurement limitations and safety.
20A The maximum current that you can measure at this
terminal is 20 amps DC/AC. This terminal is fuse
protected. For your safety during continuous
measurements, keep the duty cycle within 30 seconds in
use and more than 15 minutes in rest.
mA The maximum current that you can measure at this
terminal is 200mA DC/AC. This terminal is fuse
protected.
To avoid electrical shock or instrument damage, do not
connect the Common Input Terminal COM to any source
of more than 500 Volts with respect to earth/ground.
The maximum voltage this meter can measure is 1000V
DC or 750V AC.
Be extra careful when making high-voltage measurements.
DO NOT TOUCH THE TERMINALS OR PROBE
ENDS.
Refer to the complete operating instructions.
Indicates protection class II, double insulation.
