Smart Pro, Smart & Secure installation instructions
11. Specications
Technical Specications Smart Pro
SDO-9V3
Smart
SDO-7V3
Secure
SDO-6V3
Rated voltage range: 230V - 240V. 230V - 240V. 230V - 240V.
Rated frequency: 50Hz 50Hz 50Hz
Rated power input: 220W 225W 225W
Door opening:
Maximum Door Area:
Maximum Door Weight:
18m
2
300kg*
18m
2
235kg*
18m
2
235kg*
Door must be well balanced and able to be operated by hand, as per warranty conditions and AS/NZS 4505:2012
Minimum headroom 57mm 57mm 57mm
Rated Operating Time 4 mins 4 mins 4 mins
Rated Temp +5
o
C to +40
o
C +5
o
C to +40
o
C +5
o
C to +40
o
C
Short Term Peak force: 1400N 1100N 1100N
Door travel speed (mm/sec) 125mm 180mm 180mm
Rated load 450N 400N 400N
Maximum lifting under spring
tension
200N (20kg) 200N (20kg) 200N (20kg)
Receiver type Multi-frequency Multi-frequency Multi-frequency
Receiver code storage capacity 64 X 4-button Transmitters 64 X 4-button Transmitters 64 X 4-button Transmitters
Transmitter battery CR2032 (3 Volts) CR2032 (3 Volts) CR2032 (3 Volts)
Courtesy light 2 x LED (modules) 1 x LED (module) 1 x LED (module)
Network connectivity Network ready
(Smart hub already installed)
Network ready
(Smart hub already installed)
Requires optional
(Smart Phone Control Kit)
* Gross door weight, including all ttings
Note: During the open and close cycles, intermittent operations may occur in areas which experience very strong
winds. The strong wind puts extra pressure on the door and tracks which may in turn intermittently trigger the safety
obstruction detection system.
