B&G LCD Plotter
Part 2 - Operating Information
HB-0847-02
2-13
2.12 INFORMATION WINDOWS IN NAVIGATION MODE
Press DATA to display the following windows:
2.12.1 Speed Windows
If no route is plotted, this small window will appear
containing only the boat speed (knots), the course
and chart range.
The calculation of time of travel is based upon
information previously collected from the data input.
a) - Speed over ground in knots
b) - Distance to the next waypoint
c) - Time to reach next waypoint from present position
d) - Arrival time
e) - Chart range
a
b
c
d
e
