5. Status indicators - Displays current status of the processors audio processor. Indicators have been supplied to
show when the DSP is decoding Dolby Digital ‘
Digital’, Dolby Pro Logic ‘
Pro Logic’, or DTS audio. There is
an indicator to show the input to the S/PDIF digital receiver is 96kHz 24 bit data ‘96/24’ or an analog input that is
being sampled using 96kHz/24bits. Finally, there is an indicator to show processed audio is sourced from the
selected analog input ‘Analog’. See MODE OPERATION
6. Display - The processor display is a 16 character alphanumeric fluorescent display. Displays current status of
processor and any changes being performed.
10
p/n 12857 Rev. 0717A
