Excess Gain using a 90% White Card—100/110/300/310 mm Models
Table 6: Excess Gain ( Excess Gain
2
)
Response Speed (ms) · at 25 mm (100/300 mm models)
· at 35 mm (110/310 mm models)
· at 100 mm (100/300 mm models)
· at 110 mm (110/310 mm models)
· at 300 mm (100/300 mm models)
· at 310 mm (110/310 mm models)
1.5 200 100 20
3 200 100 20
10 1000 (500) 500 (250) 100 (50)
25 2500 (1000) 1250 (500) 250 (100)
50 5000 (2500) 2500 (1250) 500 (250)
Excess Gain using a 90% White Card—600/610 mm Models
Table 7: Excess Gain ( Excess Gain
3
)
Response Speed
(ms)
· at 25 mm (600 mm models)
· at 35 mm (610 mm models)
· at 100 mm (600 mm models)
· at 110 mm (610 mm models)
· at 300 mm (600 mm models)
· at 310 mm (610 mm models)
· at 600 mm (600 mm models)
· at 610 mm (610 mm models)
2 280 110 25 6
5 280 110 25 6
15 1000 (360) 400 (150) 80 (30) 20 (7)
25 2000 (1000) 800 (400) 160 (80) 40 (20)
50 4000 (2000) 1600 (800) 320 (160) 80 (40)
Environmental Rating
IP67 per IEC60529
IP68 per IEC60529
IP69K per DIN 40050-9 per DIN40050-9
Vibration
MIL-STD-202G, Method 201A (Vibration: 10 Hz to 60 Hz, 0.06 inch (1.52 mm) double
amplitude, 2 hours each along X, Y and Z axes), with device operating
Shock
MIL-STD-202G, Method 213B, Condition I (100G 6x along X, Y, and Z axes, 18 shocks),
with device operating
Operating Conditions
–10 °C to +50 °C (+14 °F to +122 °F)
35% to 95% relative humidity
Storage Temperature
–25 °C to +75 °C (–13 °F to +167 °F)
Required Overcurrent Protection
WARNING: Electrical connections must be made by
qualified
personnel in accordance with local and national
electrical codes and regulations.
Overcurrent protection is required to be provided by end product application per the
supplied table.
Overcurrent protection may be provided with external fusing or via Current Limiting, Class
2 Power Supply.
Supply wiring leads < 24 AWG shall not be spliced.
For additional product support, go to www.bannerengineering.com.
Supply Wiring (AWG) Required Overcurrent Protection (Amps)
20 5.0
22 3.0
24 2.0
26 1.0
28 0.8
30 0.5
Certifications
Banner Engineering Europe Park Lane, Culliganlaan 2F bus
3, 1831 Diegem, BELGIUM
Turck Banner LTD Blenheim House, Blenheim Court,
Wickford, Essex SS11 8YT, Great Britain
Industrial
Control
Equipment
3TJJ
Class 2 power
UL Environmental Rating: Type 1
chemical compatibility certified
ECOLAB is a registered trademark of Ecolab USA Inc. All rights reserved.
Advanced Capabilities
FCC Part 15
This device complies with Part 15 of the FCC Rules. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation is subject to the following
two conditions: 1) This device may not cause harmful interference; and 2) This device must accept any interference received, including interference
that may cause undesired operation.
Industry Canada
This device complies with CAN ICES-3 (A)/NMB-3(A). Operation is subject to the following two conditions: 1) This device may not cause harmful
interference; and 2) This device must accept any interference received, including interference that may cause undesired operation.
Cet appareil est conforme à la norme NMB-3(A). Le fonctionnement est soumis aux deux conditions suivantes : (1) ce dispositif ne peut pas
occasionner d'interférences, et (2) il doit tolérer toute interférence, y compris celles susceptibles de provoquer un fonctionnement non souhaité du
dispositif.
2
•
excess gain available in 10 ms, 25 ms, and 50 ms response speeds only
•
excess gain provides increased noise immunity
3
•
excess gain available in 15 ms response speed only
•
excess gain provides increased noise immunity
Q4X Stainless Steel Laser Sensor with Dual Discrete Outputs and IO-Link
P/N 190073 Rev. G www.bannerengineering.com - Tel: + 1 888 373 6767 9
