2. Introduction to CS-100
2. INTR ODUCTION TO CS-100
Overview
• About the CS-100
• About the Base Unit
• About the Button
• Mobile Device Support
2.1 About the CS-100
CS-100 sets
CS-100 makes connecting to the meeting room’s video s ystem a matter of clicking a Button. This CS-100 only he lps the presenter
get the presentation on-screen in a second, but it also allows the other people in the meeting to participate more actively. The result
is enhanced meeting effi ciency and better decision-making.
At the mom ent 3 different sets are av ailable on the m arket. Each set is sold in its specific region and it can only be used in that
specific region.
Components CS-100 set
A standard CS-100 set consists of a B ase Unit and 1 Button. Depending on the location where you buy the product, the software of
the Base Unit is different. If needed, you can buy additional Buttons.
1
2
Image 2-1
1 Base unit
2Button
Accessories included
Depending on the country where you buy the produ ct, the following regionalized accessories are also included in the CS-100 box.
Regional version
Contains
Accessories included
R9861510xx
2
• R9861510
• 1x R9861500D01
• DC adapter with AC clips type A, C,
G, I
• Printed s afety manual
Contact your local sales represent
ative for the correct regional variant to be used in your country.
2. xx=EU, CN, NA,
R5900024 CLICKSHARE CS-100 19/03/2018 5

Barco CLICK SHARE CS-100 Specifications

General

Model	CS-100
Category	Projector Accessories
Wireless Standard	IEEE 802.11 a/b/g/n
Frequency Band	2.4 GHz and 5 GHz
Video Outputs	HDMI
Number of Users	Up to 8
Security	WPA2-PSK
Output Resolution	Up to 1920x1080
Number of Sources at the Same Time on Screen	1
Number of Simultaneous Connections	Up to 8
Wireless Sharing	Yes
Frame Rate	30 fps
ClickShare Buttons	1
Power Consumption	Typical 6W
Compatibility	Windows, macOS
Connectivity	HDMI
Weight	600g
Base Unit Dimensions	205mm x 115mm x 45mm / 8.1” x 4.5” x 1.8”
Dimensions	205mm x 115mm x 45mm
