Barco CLICK SHARE CS-100 User Manual

3. Getting started
3. GETTING STARTED
Overview
• Activating the bas e unit
•BasicUse
• User Interface
• Capture more
• Sha red desktop: primary - extended
•Audioconfiguration
• Pairing
3.1 Activating the base unit
About power mode
The Base Un it is powered via an external power adapter. Once connected, the B ase Unit is automatically switched in standby mode.
For more information about power connection, see C S-100’s installation ma nual.
Standby button
1. Push the button shortly.
Image 3-1
Standby button
When the Base Unit was on, it goes to standby
When the Base U nit wa s in standby, it starts up.
3.2 Basic Use
Basic functionality
When entering a meeting room equipped with ClickShare and if the display is not in s creensaver mode, the ClickShare wallpaper is
shown on the display. The content of the wallpaper depends on the setup.
Starting to use ClickShare is no w very simple.
To start using ClickShare
1. Take a Button and Insert the Button into a USB port of your laptop.
R5900024 CLICKSHARE CS-100 19/03/2018
9

Barco CLICK SHARE CS-100 Specifications

General

Model	CS-100
Category	Projector Accessories
Wireless Standard	IEEE 802.11 a/b/g/n
Frequency Band	2.4 GHz and 5 GHz
Video Outputs	HDMI
Number of Users	Up to 8
Security	WPA2-PSK
Output Resolution	Up to 1920x1080
Number of Sources at the Same Time on Screen	1
Number of Simultaneous Connections	Up to 8
Wireless Sharing	Yes
Frame Rate	30 fps
ClickShare Buttons	1
Power Consumption	Typical 6W
Compatibility	Windows, macOS
Connectivity	HDMI
Weight	600g
Base Unit Dimensions	205mm x 115mm x 45mm / 8.1” x 4.5” x 1.8”
Dimensions	205mm x 115mm x 45mm
