Barco ClickShare CX-20 set Gen 2 User Manual

R5900102 /00 CX-2038
2. Connect the other side to a LAN.
4.11 Power connection
About power
An external power adapter is delivered with the product. The output rate is 12 VDC 2A.
CAUTION: Once the Base Unit is powered, it starts up. Then the power button can be used to
switch on or off.
How to connect the external power adapter
1. Plug the barrel connector of the power adapter into the power input of the Base unit.
2. Slide a power input adaptor piece (US, AU, IN, CH, EU or UK) on the power adapter of the ClickShare until it
clicks. Use the one
which is applicable in your country.
Image 4-7: Power adapter
3. Connect the power cable to the wall outlet.
4.12 Starting up for the first time
How to startup
The following steps are necessary before the Base Unit can be used:
1. Connect the screen, all USB devices and the power to the Base Unit.
2. The Base Unit reboots when the update is finished.
3. Base unit needs Internet access to start up for the first time. The Base Unit updates to the latest firmware
version.
4. Register and configure your device in XMS cloud.
5. Pair the buttons with the Base Unit.
6. Base Unit is ready to use.
CX-20 Installation

Barco ClickShare CX-20 set Gen 2 Specifications

General

Wireless Conferencing	Yes
Network Connectivity	Wi-Fi, Ethernet
Native Protocols	AirPlay, Google Cast, Miracast
Relative Humidity	20% to 80% (non-condensing)
Video Output	HDMI
Supported Resolutions	Up to 4K Ultra HD (3840x2160)
Operating System Compatibility	Windows, macOS, Android, iOS
Security	WPA2
USB Ports	1 x USB Type-C, 1 x USB Type-A
Resolution	Up to 4K Ultra HD (3840x2160)
Operating Temperature	0°C to +40°C
Storage Temperature	-20°C to +60°C
