Barco ClickShare CX-20 set Gen 2 User Manual

R5900102 /00 CX-2032
4.1 Installation methods for the Base Unit
For optimal performance, install the Base unit close to the display and avoid obstacles between the
Base unit and the Buttons.
Make sure not to install the Base Unit in a metal enclosure.
Physical installation
The Base unit can be installed in different ways in a meeting room.
• Table mount
• Wall mount
• Ceiling mount
Standalone or network integration
The Base Unit can be use as standalone unit or integrated in a corporate network.
• Out-of-the-box use
• Out-of-the-box use with Ethernet link
4.2 Table mounting
Overview
Put the Base Unit directly on the meeting room table.
The total weight of the Base Unit is 530 g.
4.3 Wall or ceiling mounting
About wall or ceiling mounting
A mounting base is used to mount the CX-20 to the wall or ceiling. This base has key-shaped screw holes to
allow you to fasten the base to a wall or ceiling or you can use the self-adhesive layer to mount the base. Once
you determine the location for your device follow the next procedure to mount the device.
Mounting with screws
1. Take the mounting base out of the package.
2. Place the mounting base on the wall or ceiling and mark the screw holes (1).
CX-20 Installation

Barco ClickShare CX-20 set Gen 2 Specifications

General

Wireless Conferencing	Yes
Network Connectivity	Wi-Fi, Ethernet
Native Protocols	AirPlay, Google Cast, Miracast
Relative Humidity	20% to 80% (non-condensing)
Video Output	HDMI
Supported Resolutions	Up to 4K Ultra HD (3840x2160)
Operating System Compatibility	Windows, macOS, Android, iOS
Security	WPA2
USB Ports	1 x USB Type-C, 1 x USB Type-A
Resolution	Up to 4K Ultra HD (3840x2160)
Operating Temperature	0°C to +40°C
Storage Temperature	-20°C to +60°C
