5. Mechanical setup of display wall with pedestals
5.4 Installation of the pedestal
The following table shows the components of the pedestal 1200mm, R876787. Except for the length of the verti-
cal profiles (R869377), the components of all pedestals are (almost) identical.
Article no. Description Quantity picture
R879297
NSL
-5521 PED TOP V4
1
1
R867141
FRMC NSL1 PF Y 906.6
2
7
R879296
NSL
-5521 PED PF X V4
1
8
B361304
SCR ASS D188K M8X25 STZN
20
9
R867120
FRMC NSL1 FEET SUP
2
10
B356318
FOOT REG D45 H145 M16STST
2
11
B360780
WSHR D433 D17 D28 SS
2
G235531
NUT D934 M16 STZN
2
R869262
FRM NSL1 FLOOR BRKT
2
12
R867885
FRMC NSL1 TRIPOD
4
2
R879299
NSL
-5521 CABLE HUB V4
1
5
R870780
FRM NSL1 TOP CNN HOLDER
2
6
R858766
F
RMC NSL1 PWR STRIP SUP
1
3
R819000
FRM ATL67C4 CBL TIE HLR
3
4
A577351
CBLA TIE B L400 W5
10
R879298
NSL
-5521 PF PIN CNN HOR V4
6
13
B593021
BOXKIT NSL
-5521 PED
1
R591702
LBL GENERIC 148X105 PCK
1
R764734
GROUNDING KIT OVERVIEW C
1
Pedestal
10
The vertical profiles have a cross section of
90x45.
In the following the part where the foot is insert-
ed will be called "rear part".
Barco - LCD 5521 V4 - R591734 - Installation manual - Revision 00 - March-2017
_____________________________________________________________
33
