6. Mechanical setup of display walls with wall mount solutions
6 Mechanical setup of display walls with wall mount solutions
Pedestal
82
The upper system features an air channel
(NSL-5521)
The lower system does not feature an air channel
(OVD5521, KVD5521, IVD5521, HVD5521).
The following pictures and steps apply for
OVD/KVD/IVD/HVD
although some of the pictures
show the NSL-5521 system with air channel.
Wall mount
01
The NSL wall mount solution is based on alu-
minium profiles fixed to the wall
Wall mount
02
The mechanics to house the panels hangs in
these aluminum profiles
Barco - LCD 5521 V4 - R591734 - Installation manual - Revision 00 - March-2017
