Barco LCD 5521 V4 User Manual

7. Cabling
Make sure to guide the cables BEHIND the sheet
metal of the gas spring mechanism!!
(The picture shows a setup wi
th pedestals but the
cabling principle is the same for wall mount solu-
tions!)
Step
06
Make sure to guide all cables.
Fix them using the cable tie holders (vertical di-
rection) and the fixation holes (horizontal direc-
tion).
Care for a clear layout.
Step
07
For LAN cabling / BCMC please refer to the user
manual of Barco Wall Control Manager.
Barco - LCD 5521 V4 - R591734 - Installation manual - Revision 00 - March-2017
