Barco LCD 5521 V4 User Manual

8. Installation of the displays
Step
13
For transportation security, the interface frame
is
locked by means of two transportation lock
screws, one at the left and one at the right
Please note:
The latches may be in the open position and
thus the interface frame might swing forward in
an uncontrolled way!
Step
14
Take care!
Hold the frame into position!
Only remove one transportation lock
screw (e.g.
the left one).
Make sure to close this side!
Switch to the next side (e.g. the right one).
Hold the frame into position.
Remove the transportation lock screw.
Make sure to close this side!
Barco - LCD 5521 V4 - R591734 - Installation manual - Revision 00 - March-2017
_____________________________________________________________
80
