K5902108-04 Coronis Fusion 4MP / 6MP16
3. Lift the plastic frame to uncover the fixation screws.
4. Unscrew the four fixation screws fixing the panel to the stand.
5. Attach the panel firmly to the arm using 4 screws M4 x 10 mm.
WARNING: Never move a display attached to an arm by pulling or pushing the display itself.
Instead, make sure that the arm is equipped with a VESA approved handle and use this to move the
display.
Please refer to the instruction manual of the arm for more information and instructions.
2.9 First time starting up
Overview
You are now ready to start up your Coronis Fusion 4MP / 6MP for the first time.
1. Switch on your Coronis Fusion 4MP / 6MP as described in “Standby switching”, page 21.
2. Turn on the computer connected to your display.
If you have properly installed your display and display controller, the Windows start-up messages will appear
once the boot procedure is finished.
Display installation
