K5902108-04 Coronis Fusion 4MP / 6MP 33
4.19 Image source selection modes
About image source selection modes
Your Coronis Fusion 4MP / 6MP automatically detects the number of video input signals connected, attaches
them to the correct display side and applies the correct video settings to it (resolution, video encoding mode,
refresh rate,...). However, it may be needed to manually select the video input signal(s) to be displayed on a
certain display side or to adjust certain video settings yourself. The start to this is selecting one of the following
image source selection modes available for your display:
Automatic: In this mode, your display automatically detects the connected video input signals, attaches
them to the correct display side and applies the correct video settings to it (resolution, video encoding
mode, refresh rate,...). No video settings are available when this mode is selected.
One image source: This mode is intended for displaying and manually configuring only one connected
video input signal. When selecting this mode, the video settings become available for the selected video
input signal.
Two image sources: This mode is intended for displaying and manually configuring two connected video
input signals (one on each display side). When selecting this mode, the video settings become available
for the selected video input signal on each side of the display.
Expert mode: This mode is intended for displaying and manually configuring one or two connected video
input signals. When selecting this mode, the video settings become available for both video input signals
on both sides of the display.
To select an image source selection mode:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources menu.
3. Enter the Image Source Selection submenu.
4. Select one of the available image source selection modes and confirm.
4.20 Video input signals
Your Coronis Fusion 4MP / 6MP display automatically detects the connected video input signals.
Manually video input configuration is possible, but then your displays image source selection mode
should be set to allow this. Please refer to Image source selection modes, page 33 to do this.
About input configuration
Depending on the image source selection mode, following inputs can be configured:
Menu Image source selection
mode
Input Signal 1 Image Source Connector configuration (DisplayPort 1/2, DVI 1/2)
for the input signal.
Left Input Signal 2 Image Sources Connector configuration (DisplayPort 1, DVI 1) for
the left input signal.
Right Input Signal Connector configuration (DisplayPort 2, DVI 2) for
the right input signal.
Left Expert mode Input signal (input 1/2) configuration for the left
side of the screen.
Right Input signal (input 1/2) configuration used for the
right side of the screen.
Input 1 signal Connector configuration (DisplayPort, DVI) for
input 1 signal.
Input 2 signal Connector configuration (DisplayPort, DVI ) for
input 2 signal.
Auto input selection Automatic input selection configuration.
