K5902108-04 Coronis Fusion 4MP / 6MP50
Immunity test
IEC 60601 test levels
Compliance level
Electromagnetic
environment – guidance
Conducted RF
IEC 61000-4-6
3 Vrms (6 Vrms in ISM
bands)
150 kHz to 80 MHz
3 Vrms (6 Vrms in ISM
bands)
Portable and mobile RF
communications
equipment should be used
no closer to any part of the
Coronis Fusion 4MP /
6MP, including cables,
than the recommended
separation distance
calculated from the
equation applicable to the
frequency of the
transmitter.
Recommended
separation distance
d = 1.2√P
d = 1.2√P 80 MHz to 800
MHz
d = 2.3√P 800 MHz to 2.7
GHz
where P is the maximum
output power rating of the
transmitter in watts (W)
according to the
transmitter manufacturer
and d is the recommended
separation distance in
meters (m).
Field strengths from fixed
RF transmitters, as
determined by an
electromagnetic site
survey,
6
should be less
than the compliance level
in each frequency range.
7
Interference may occur in
the vicinity of equipment
marked with the following
symbol:
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz to 2.7 GHz
3 V/m
At 80 MHz and 800 MHz, the higher frequency range applies.
These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
Important information
6: Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,
amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the
electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured
field strength in the location in which the Coronis Fusion 4MP / 6MP is used exceeds the applicable RF compliance level above, the
Coronis Fusion 4MP / 6MP should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as reorienting or relocating the Coronis Fusion 4MP / 6MP.
7: Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
