5. Advanced operation
5.19 Display o rientatio n
About Display orientation
Your display automatically detects its physical orientation (portrait or landscape) and, by default, automat-
ically adjusts the image orientation to this. This means that when your display is physically rotated, the
image will rotate along.
The OSD menu however, allows to overrule this behavior and force the image orientation to portrait or
landscape regardless of the physical orientation of the display. This may be especially useful when oper-
ating your display with the screen facing upwards.
To set the Display orientation
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources menu.
3. Enter the Display Orientation submenu.
4. Select Landscape/Portrait/Automatic as desired and confirm.
5.20 Video input sig nals
About input signals
The available input signals for your display are:
DisplayPort 1 The input corresponding to the DisplayPort
connector.
DVI 1 The input corresponding to the DVI connector.
Automatic Selection
The input is automatically selected.
To manually select a video input signal:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Source menu.
3. Enter the Input Signal submenu.
4. Select one of the available input signals and confirm.
5.21 Video enco din g modes
About video encoding modes
Video encoding modes specify how the color and luminance information is encoded in the video signal.
In consumer displays, this is usually done by a limited 8-bit encoding mechanism. Your Coronis 5MP
however, features 10-bit encoding enabling it to better match the DICOM defined grayscale range. Such
an extensive range is necessary to comply with
the guidelines set forward by the latest medical guidelines.
The available video encoding modes for your display are listed below.
Please note that the display controller connected to your display might not always sup-
port all these v ideo encoding modes.
B4100592 CORONIS 5MP 05/08/2014 29
