3. Display installation
3.5 Routing the cables & Reattach the connec tor compartment
cover
To route the cables
1. Route all connected cables through the cable routing channel in the stand of your display.
Tip: The cable straps at the inside of the connector compartment al
low you to fix the cables for better
shielding of the cables.
To Reattach the connector compartment cover
1. Reattach the connector compartment cover by sliding the cover’s bottom in position and then push the
cover’s top. You’ll hear a “click” sound of the cover’s clips when the connector compartment cover is
in position.
3.6 VESA-mount installatio
n
WARNING: N ever move a display attached to an arm by pulling or pushing the display
itself. Instead, make su
re that the arm is equipped with a VESA approved handle and
use this to move the display.
Please refer to the instruction manual of the arm for more information and instructions.
12 K5902067 NIO 3MP LED DISPLAY 10/04/2013
