Power cable recommendations
When using long power cables, the DC voltage at the power input of the
display might be too low for the display to operate safely.
Therefore, we recommend the following maximum power cord lengths:
* resistance at 50 °C
Note:
Cable type Resistance/
wire
[Ohm/km] *
# wires
parrallel
Effect Resis-
tance
[Ohm/km]
MDSC-1119
max. cable
length
MDSC-2124
max. cable
length
2x1,5mm² 14.87 1 14.87 78 13
4x0,75mm² 29.07 2 14.54 79 13
4x1mm² 21.80 2 10.90 106 17
6x0,75mm² 29.07 3 9.69 119 19
4x1,5mm² 14.87 2 7.44 155 25
6x1mm² 21.80 3 7.27 159 26
6x1,5mm² 14.87 3 4.96 233 38
MDSC-1119 MDSC-2124
Min Input voltage [V] 18 22
Current[A] 2.6 4
Max allowable voltage drop[V] 6 1.5

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
