Introduction
19
Rear
Figure 2: Rear view
1. Connector compartment cover.
Remove to get access to the signal connectors.
2. Compartment cover levers to lock/unlock the cover.
3. VESA mount screw holes.
Connectors
The connector configuration may depend on the customer’s
requirements. Below is a description of the default connector
configurations.
1
2
3
