Preface
14
Explanation of symbols
Symbols on the display and / or power supply
On the display or power supply, you may find the following symbols
(nonrestrictive list):
Indicates compliance to the essential require-
ments of the Directive 93/42/EEC
Indicates compliance with Part 15 of the FCC
rules (Class A or Class B)
or
Indicates the display is approved according to
the UL regulations
or
Indicates the display is approved according to
the c-UL regulations
Indicates the display is approved according to
the DEMKO regulations
Indicates the display is approved according to
the CCC regulations
Indicates the USB connectors on the display
Indicates the manufacturing date
Indicates the temperature limitations for the
display to operate within specs

Other manuals for Barco MDSC-1119

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Barco MDSC-1119 and is the answer not in the manual?

Barco MDSC-1119 Specifications

Display Specifications IconDisplay Specifications
technologyTFT Active Matrix LCD
native resolution1280 x 1024
active screen diagonal19 inches
active screen area14.8 x 11.9 inches
pixel pitch0.294 mm
brightness300 cd/m2
contrast ratio700:1
viewing angle178 degrees
Connectivity and Control IconConnectivity and Control
analog video inputs1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputsDVI-I
communicationRS232 (9-pin D-Sub)
Supported Resolutions and Formats IconSupported Resolutions and Formats
horizontal scan frequencies15-100 kHz
vertical scan frequencies50-120 Hz
bandwidth165 MHz
Power Requirements IconPower Requirements
external DC power supply90-264 VAC
display voltage20-24 VDC
power consumption80 Watt max
Physical Characteristics IconPhysical Characteristics
display dimensions427 x 356 x 81 mm
display weight8 kg
mounting75 & 100mm VESA
