93R5911443 /03 UDM
Image 8–39 The upper line is colored blue, the other sides are colored white
5. Use the arrow keys to select the side of the picture that needs a correction and confirm.
Image 8–40 Symmetric bow correction
6. Use the arrow keys to adjust the angle and linearity (length) of the vectors. Press enter to confirm and
switch between angle and length.
Tip: The angle is adjusted by using the up and down arrow keys. The linearity is adjusted by using the
left and right arrow keys.
The correction will occur symmetrically on each side of the center of the highlighted side.
7. Repeat this step for all sides of the picture that has to be corrected, until the desired transformation has
been achieved.
Image 8–41 Example of a symmetric bow correction
GUI – Installation
