R5906113 /08 UDX 65
Color space YCbCr
Color depth 10 bpc
Chroma sampling 4:2:2
Not supported
3
• Audio support
• 3D support
• Interlaced support
• Segmented frame support
• Loop-through functionality
Video timings
progressive
4
Type Port type Format
HD-SDI Single link
Quad link
Up to 1920 x 1080 @24 Hz
Up to 1920 x 1080 @25 Hz
Up to 1920 x 1080 @30 Hz
Up to 1280 x 720 @50 Hz
Up to 1280 x 720 @60 Hz
3G-SDI Level A Single link
Quad link
Up to 2048 x 1080 @50 Hz
Up to 2048 x 1080 @60 Hz
3G-SDI
“BarcoLink”
Single link
Quad link
1920 x 1200 @50 Hz, @59.94 Hz and
@60 Hz.
Input specifications – HDMI Input
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
Pixel rate 25 – 600 MHz pixel clock
HDCP support • HDCP 1.x
• HDCP 2.2
• RGB 4:4:4
Color space • YCbCr 4:2:0
• YCbCr 4:2:2
• YCbCr 4:4:4
• RGB 4:4:4
Color depth • 24 bpp
• 30 bpp
• 36 bpp
3D support • Field sequential 3D (Active 3D)
- Frame-packed
- Top Bottom progressive
- Side-by-side progressive
• Passive 3D not supported.
For future release • Interlaced support
Audio not supported
Input & Communication
3: The Mark II board has support for
4: For the full list of video timings, see Appendix
