R5906113 /08 UDX66
Video timings
4
• Up to 4096 x 2160 @24 Hz
• Up to 4096 x 2160 @25 Hz
• Up to 4096 x 2160 @30 Hz
• Up to 2048 x 1080 @48 Hz
• Up to 4096 x 2160 @50 Hz
• Up to 4096 x 2160 @60 Hz
Native video timings • UDX-U-series: 1600 x 1200 @60 Hz
• UDX-W-series: 1920 x 1200 @60 Hz
• UDX-4k-series: 3840 x 2400 @60 Hz
CAUTION: The HDBaseT inputs can bridge a distance of 100 m but are sensitive to radiated
electromagnetic interference: radiated electromagnetic interference (e.g. from GSM or switching
inductive or capacitive loads) within the limits of electromagnetic compatibility requirements of 3 V/
m can cause random flashes or temporary loss of the projected image.
As such, shielded CAT-6 cables with metal RJ-45 connectors are recommended; choose cable
length no longer than required and route HDBT cable optimally screened from possible sources of
electromagnetic emission.
Input specifications – HDBaseT inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
Pixel rate 25 – 297 MHz pixel clock
Color space • YCbCr 4:2:2
• YCbCr 4:4:4
• RGB 4:4:4
Color depth • 24 bpp
• 30 bpp
• 36 bpp
HDCP support HDCP 1.x supported on HDBaseT Input 1
Network support Yes, on HDBaseT Input 1
For future release • 3D support
• Interlaced support
Audio not supported
Video timings
progressive
4
Layout mode Supported formats
Standard layout (1x1
layout)
• Up to 4096 x 2160 @24 Hz
• Up to 4096 x 2160 @25 Hz
• Up to 4096 x 2160 @30 Hz
• Up to 2048 x 1080 @48 Hz
• Up to 2560 x 1600 @50 Hz
• Up to 2560 x 1600 @60 Hz
2 Column mode (2x1
layout)
• 1920 x 2160 @50 Hz
• 1920 x 2160 @60 Hz
• 2048 x 2160 @50 Hz
• 2048 x 2400 @60 Hz
Native video
timings
• UDX-U-series: 1600 x 1200 @60 Hz
• UDX-W-series: 1920 x 1200 @60 Hz
• UDX-4k-series: 3840 x 2160 @60 Hz
