R5906113 /08 UDX 67
CAUTION: In order to display high resolution images (e.g.: 3840 x 2160 @60 Hz) via the DP1.2
input, the quality of the cable must be adequate, in addition the length of the cable can also
influence the performance. In case there is an issue with one of these criteria the automatic link-
training initiated by the DP-standard may decide to switch to a lower resolution.
Input specifications – DisplayPort 1.2 input
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
Pixel rate Up to 600 MHz pixel clock
Color space • YCbCr 4:2:2
• YCbCr 4:4:4
• RGB 4:4:4
Color depth • 24 bpp
• 30 bpp
• 36 bpp
Data rate support • 1.62 Gbps: Reduced Bit Rate (RBR)
• 2.7 Gbps: High Bit Rate (HBR)
• 5.4 Gbps: High Bit Rate 2 (HBR2)
HDCP support HDCP 1.4
For future release • Interlaced support
Audio not supported
3D support • Field sequential 3D (Active 3D)
• Passive 3D not supported on this board.
Video timings
progressive
4
2D / 3D Layout Mode Supported formats
2D Standard layout (1x1
layout)
• Up to 4096 x 2160 @24 Hz
• Up to 4096 x 2160 @30 Hz
• Up to 2048 x 1080 @48 Hz
• Up to 4096 x 2160 @50 Hz
• Up to 4096 x 2160 @60 Hz
• Up to 2560 x 1600 @120 Hz
Active
3D
Standard layout (1x1
layout)
• 1600 x 1200 @120 Hz
• 2560 x 1080 @120 Hz
• 2560 x 1600 @120 Hz
Native video
timings
• UDX-U-series: 1600 x 1200 @60 Hz
• UDX-W-series: 1920 x 1200 @60 Hz
• UDX-4k-series: 3840 x 2400 @60 Hz
Input & Communication
