Bard GSVS421-A - Figure 7; Figure 8 Model GPM-1 Loop Pump Module; Figure 9 Model GPM-2 Loop Pump Module

Manual 2100-317J
Page 20 of 39
0
10
20
30
40
50
60
70
0 5 10 15 20 25 30 35
Flow (GPM)
Head (Feet)
FIGURE 9
PERFORMANCE MODEL GPM-2 LOOP PUMP MODULE
0
5
10
15
20
25
30
35
0 5 10 15 20 25 30 35
Flow (GPM)
Head (Feet)
FIGURE 8
PERFORMANCE MODEL GPM-1 LOOP PUMP MODULE
FIGURE 7
TEST PLUG CAP
PETE’S TEST PLUG
SELF SEALING
DIAL FACE PRESSURE GAUGE
WITH GAUGE ADAPTOR
THERMOMETER
WATER COIL CONNECTION
AT HEAT PUMP
BARB X INSERT
BRASS ADAPTER
1" AND
3/4" MPT
