SPECIAL TORQUE SPECIFICATIONS
LUBRICATE WITH ANTI-SEIZE COMPOUND PART NO. 514-00700
Other torques, for the valves, pumps, and motors are found in the service literature for those components.
Swing Motor Mounting Bolts ....................................................................... 80 Ft. Lbs.(109 Nm)
Swing Motor Gearbox Mounting Bolts ........................................................ 80 Ft. Lbs.(109 Nm)
Turntable Bearing Bolts (upper) (Do not re-use old bolts/nuts) ................. 331 Ft. Lbs.(448 Nm)
Turntable Bearing Bolts (lower) (Do not re-use old bolts/nuts) .................. 331 Ft. Lbs.(448 Nm)
Loader Mounting Studs and Nuts ............................................................... 600 Ft. Lbs.(814 Nm)
Valve Bank Studs/Nuts:
Tighten in a clockwise pattern so that all nuts are tightened equally without binding on the valve bank.
Final torque should be:
K170 valves ............................................................................................... 44 Ft. Lbs.(60 Nm)
K220 valves ............................................................................................... 59 Ft. Lbs.(80 Nm)
L90 valves .................................................................................................. 33 Ft. Lbs.(45 Nm)
495ML MAGNUM PLUS TM
Loose or overtorqued bolts can cause death, severe
injury, or property damage. Maintain proper bolt torque.
Visually check bolts daily. Check torque every 100
hours.
In critical applications (such as Turntable Bearing Bolts
and any grade 8 or grade 9 bolts), once the old bolts
and nuts have been loosened, they must be replaced
rather than re-tightened and re-torqued. Original clamp-
ing force cannot be achieved using the old bolts and
nuts.
