Parts lists
2050 transceiver - Micro Processor / RF PCB
Click here to view Micro processor / RF schematic and overlay
PC-2000P01-A2 Micro RF PCB Parts List
Designator Description
Barrett Part
Number
C1 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C2 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C3 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C4 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C5 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C6 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C7 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C8 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C9 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C10 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C11 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C12 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C13 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C14 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C15 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C16 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C17 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C18 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C19 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C20 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C21 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C22 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C23 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C24 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C25 Cap 1uF 5% 16V 0805 Y5V CP-11674
C26 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C27 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C28 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C29 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C30 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C31 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C32 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C33 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C34 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C35 Cap 47uF 16v 10% Case D CP-11665
C36 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C37 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C38 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C39 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C40 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C41 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C42 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C43 Cap 100nF 5% 50V 0603 X7R NB CP-11666
