Barrett 2040 - 2040 Manpack Adapter - Internal Charger PCB

79
2040 Manpack adapter – Internal charger PCB
Click here to view Internal charger PCB schematic and overlay
PC-2040P29-A0 Internal Charger PCB Parts List
Designator Description
Barrett Part
Number
C1 Cap 1uF 10V +80/-20% 0603 NB CP-11721
C2 Cap 10uF 20% Electro Case B 35V SMD CP-11720
C3 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C4 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C5 Cap 47uF 20% Electro Case ? SMD CP-11706
C6 Cap 47uF 20% Electro Case ? SMD CP-11706
C7 Cap 47uF 20% Electro Case ? SMD CP-11706
C8 Cap 47uF 20% Electro Case ? SMD CP-11706
C9 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C10 Cap 3u3 16v Y5V +80/-20% 1206 NB CP-11722
C11 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C12 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C13 Cap 4u7 16v Y5V +80/-20% 1206 NB CP-11718
C14 Cap 150pF 5% 50V 0603 NPO NB CP-11686
C15 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C16 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C17 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C18 Cap 1uF 50v Y5V +80/-20% 1206 NB CP-11723
C19 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C20 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C21 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C22 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C23 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C24 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C25 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C26 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C27 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C28 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C29 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C30 Cap 1uF 50v Y5V +80/-20% 1206 NB CP-11723
C31 Cap 1uF 50v Y5V +80/-20% 1206 NB CP-11723
C32 Cap 1uF 50v Y5V +80/-20% 1206 NB CP-11723
C33 Cap 1uF 50v Y5V +80/-20% 1206 NB CP-11723
C34 Cap 1uF 50v Y5V +80/-20% 1206 NB CP-11723
C35 Cap 1uF 50v Y5V +80/-20% 1206 NB CP-11723
D1 Di BZX84C18 SOT-23 DI-03365
D11 Di MBRB1545 D2-Pak Sw/Mode Power Rectifier DI-03366
D4 Di MBRB1545 D2-Pak Sw/Mode Power Rectifier DI-03366
D7 Di BZX84C27 SOT-23 DI-03364
D8 Di BAW56 SOT23 SMD DI-03300
J1 Plug 3 pin CN-04102
L1 Ind 33uH SMD IN-15035
L2 Ind 22T L2,3,4,5 2040 Charger IN-15036
L3 Ind 22T L2,3,4,5 2040 Charger IN-15036
