2050 Transceiver – Front panel PCB
Click here to view Front panel PCB schematic and overlay
PC-2000P06-A1 Front Panel PCB Parts List
Designator Description
Barrett Part
Number
P1 Plug 5 Pin Double Row Nrml CN-04109
P2 Conn RJ-45 Modular Jack RA PCB Inverted CN-24151
P3 Plug 5 Pin Double Row Nrml CN-04109
2050 Transceiver – Rear panel PCB
Click here to view Rear Panel PCB schematic and overlay
PC-2000P05-A1 Rear Panel PCB Parts List
Designator Description
Barrett Part
Number
C1 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C2 Cap 1uF 5% 16V 0805 Y5V CP-11674
C3 Cap 10uF 20% Tant 25V Case C CP-01575
D1 Di BAV70 SMD DI-03316
D2 Di BAV70 SMD DI-03316
D3 Di GF1A DO-214BA Power DI-03354
P1 Conn Header M 34W Dual ST CN-24153
P2 Cable 2000 PA Control Loom SA-20008
P3 Conn Minifit 6pin PCB St CN-24152
P4 Conn Minifit 4pin PCB St CN-03953
P5 Conn Chassis C32-08 REC11.2 UHF S/HOL MOUNT CN-04025
P6 Conn Chassis C32-08 REC11.2 UHF S/HOL MOUNT CN-04025
P8 Cable 2000 R/Panel to PA Coax SA-20009
P10 Conn Minifit 2pin str PCB CN-03954
R1 Res 1R 1W 5% 1218 NB RE-10334
RL1 Relay EA2-12T LATCHING SMD RL-00077
Q1 Trans 2N7002 LT-1 Fet SOT23 TR-02282
U1 IC 78l05ACM SO8 IC-00076
